LED Connect emergency light 40W / 5W / IP65 / 3H / 1200 / 4000K/E - LNL324/3E

LED Connect emergency light 40W / 5W / IP65 / 3H / 1200 / 4000K/E - LNL324/3E

Name: LED Connect emergency light 40W / 5W / IP65 / 3H / 1200 / 4000K/E - LNL324/3E
Brand: NEDES
SKU: LNL324/3E
Price: 64.90 EUR
Availability: InStock

RF:

included in the price

Luminous flux (Lm):

5,000–9,999

Dimensions (mm):

1000≤

Power (W):

31–50

Producer: NEDES

Warranty: 60 months

Code: LNL324/3E

EAN: 8585040905505

Availability: in stock 53 pcs

€ 52.76 excl. VAT

€ 64.90 pcs

Watchdog Add to wishlist

Description Need advice?

Max. Power (W)

Max. Luminous flux (lm)

5,800

Dimensions (mm)

1,200

Colour of light

4000K – neutral

Colour

White

Beam angle

120°

Voltage (V)

AC180–265

Installation type

Ceiling

Light source

LED

Coverage

IP65

Dimming

Well

Colour rendering index

Ra ≥ 80

Lifetime (h)

50,000

Switching cycle (x)

30,000

Sensor

Well

Solderable

Yes (max. 1000W)

Switch

Well

Duration of emergency lighting (h)

Tensile strength level

IK08

Diffuser type

Opal

Material

Thermal PC

Net weight (g)

1384

Packaging (pcs)

1/20

The innovative NEDES LNL324/3E LED linkable emergency light combines safety and efficiency.

This LED emergency light is designed for surface mounting and can be linked with multiple luminaires.

Accessories such as adjustable brackets and suspension fittings designed for this LED emergency light provide a complete solution for efficient and intelligent lighting in a variety of environments.

The luminaire offers a choice between permanent lighting or emergency-only operation during a power cut, controlled via a standard wall switch.

Package includes:

Screws and clips for surface mounting

The LEDs are not replaceable.

Declaration of Conformity

eu_declaration_of_conformity_lnl3.pdf

Installation instructions

manual_lnl_324-3e.pdf

Photometric data

lnl324-3s-e_ies.zip

Product sheet

product_sheet_lnl324-3e.pdf
