LED connect emergency light 40W / 5W / IP65 / 3H / 1200 /4000K/E - LNL324/3E

PD
Color:
white
Coverage:
IP65
Possibly to connect:
yes
Dimension (mm):
1200
Sensor:
no
Dimmable:
no
Luminous flux (Lm):
5000-5999
Power (W):
40
RP:
power (W):

40

luminous flux (Lm):

5800

size (mm):

1200 x 83 x 73

coverage:

IP65

degree of mechanical protection:

IK08

light color (K):

4000

power switch:

no

possibly to connect:

yes

Producer: NEDES
Warranty: 60 months
Code: LNL324/3E
EAN: 8585040905505
Availability: in stock
88.83 excl. VAT
106.60 PCS
Watchdog Add to wishlist Share

The emergency LED dustproof luminaire is designed for surface mounting with the possibility of soldering with several luminaires.
-Optional permanent lighting resp. lighting only in case of power failure using a standard switch package contains:
-screws and clips for surface mounting

TECHNICAL PARAMETERS
consumption 40W / 5W in emergency mode
luminous flux 5800Lm / 600Lm in emergency mode
coverage IP65
chromaticity (light color) 4000K - neutral white
degree of mechanical protection IK08
angle of light 120°
dimension (mm) 1200 x 83 x 73
sensor 3h
possibly to connect yes (max.1000W)
power switch -
voltage AC180 - 265V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 1384
dimming no
material thermal PC
type of diffusor opal
packing 1/20
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_lnl3.pdf

Installation instruction

manual_lnl_324-3e.pdf

Photometric data

lnl324-3s-e_ies.zip

Product sheet

product_sheet_lnl324-3e.pdf
