LED linear lightsLED linear IP65

LED connecting light + sensor 36W / IP65 /1200 / 4000K - LNL322/1S

Sensor PE
Light angle:
120
RP:
Luminous flux (Lm):
3000-4999
Installation type:
Ceiling
Dimension (mm):
1000≤
Power (W):
31-50
Light source:
LED
Coverage:
IP65
Dimming:
No
Sensor:
Yes
Color rendering index:
Ra≥80
Producer: NEDES
Warranty: 36 months
Code: LNL322/1S
EAN: 8585040912053
Availability: in stock more than 300 pcs
€ 24.96 excl. VAT
€ 30.70 pcs
Watchdog Add to wishlist Share

Description Need advice?
TECHNICAL PARAMETERS
consumption 36W
luminous flux 4140Lm
coverage IP65
chromaticity (light color) 4000K - neutral white
degree of mechanical protection IK08
angle of light 120°
dimension (mm) 1200 x 51 x 31
sensor yes ( 15sec / 5 lx / 4m )
possibly to connect yes (max.1000W)
power switch -
voltage AC180 - 265V
lifespan 30 000h
swiching cycle 20 000 x
weight netto (g) 383
dimming no
material thermal PC
type of diffusor opal
packing 1/25
LED´s aren´t possible to change




Declaration of conformity

eu_declaration_of_conformity_lnl3.pdf

Installation instruction

manual_lnl322-1s.pdf

Photometric data

lnl322_ies.zip
