The NEDES brand LED linear light is designed for both indoor and outdoor lighting. Its main purpose is to provide efficient, even, and energy-saving lighting with a long lifespan.
This linear light, with the option of linking multiple lights, allows you to connect several fixtures into one series, thereby achieving lighting for larger areas or rooms.
SMART LED
Wifi 2.4GHz (TUYA/SmartLife App - AMAZON ALEXA / GOOGLE HOME) + BT(BLE)
Dimming
Night mode
Color temperature change (3000K – 6500K)
Memory of the last setting after turning off with the switch (provided that the light stays on for at least 10 seconds after the last setting, followed by at least 10 seconds of being off)
Memory of the last setting after turning off in the app
Easy installation
Non-replaceable LEDs
| TECHNICAL PARAMETERS | |
| consumption | 40W |
| luminous flux | 5200Lm |
| coverage | IP65 |
| chromaticity (light color) | 3000K-6500K |
| degree of mechanical protection | IK08 |
| angle of light | 120° |
| dimension (mm) | 1200 x 68 x 60 |
| sensor | - |
| possibly to connect | yes (max.1000W) |
| power switch | - |
| voltage | AC180 - 265V |
| lifespan | 50 000h |
| swiching cycle | 30 000 x |
| weight netto (g) | 784 |
| dimming | yes (APP) |
| material | thermal PC |
| type of diffusor | opal |
| packing | 1/25 |
| LED´s aren´t possible to change |
Declaration of conformity
eu_declaration_of_conformity_lnl3.pdf
Manual
manual_instalation_lnl3343w.pdf
Photometric data
