LED floodlightsLED LF2 series

LED HQ floodlight 20W + handle / 4000K / BK / H - LF2022H

PF
Color:
black
Sensor:
no
Luminous flux total (Lm):
1000-1999
Angle of light:
120°
Power (W):
20
RP:
power (W):

20

luminous flux (Lm):

1800

coverage:

IP44

light color (K):

4000

degree of mechanical protection:

IK08

sensor:

no

Producer: NEDES
Warranty: 36 months
Code: LF2022H
EAN: 8585040903594
Availability: in stock
€ 29.00 excl. VAT
€ 34.80 PCS
Watchdog Add to wishlist Share

Description Need advice?
TECHNICAL PARAMETERS
consumption 20W
luminous flux 1800Lm
coverage IP44
chromaticity (light color) 4000K - neutral white
degree mechanical protection IK08
angle of light 120°
dimension (mm) 176 x 250 x 21
sensor 1,2m 3x1.0mm VDE, EU
voltage AC220 - 265V
lifespan 30 000h
swiching cycle 25 000 x
weight nettto (g) 580
dimming no
material HQ aluminium-matt anticorossive coating
type of diffuser 4.0mm temepered reflective glass, ANTI-dazzling
packing 1/10
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_lf2.pdf

Photometric data

lf2_20w_ies.zip

Product sheet

product_sheet_lf2022h.pdf
