LED light High Bay UFO 150W / IP65 / 5000K / 0-10V - LU422/1

NEW PB
RF:
incl. in price
Luminous flux (Lm):
20000≤
Dimension (mm):
≤500
Power (W):
101-150
Light source:
LED
Coverage:
IP65
Dimming:
Yes
Sensor:
No
Color rendering index:
Ra≥80
Producer: NEDES
Warranty: 60 months
Code: LU422/1
EAN: 8585040919052
Availability: in stock more than 200 pcs
121.14 excl. VAT
149.00 pcs
Watchdog Add to wishlist Share

The modern industrial LED light, also known as a UFO light or UFO lamp, from the NEDES brand, provides efficient illumination with neutral white light.

The powerful Highbay LED lamp ensures high luminous output and energy efficiency.

It is ideal for various indoor and outdoor lighting needs in industrial environments such as production and industrial halls, hangars, large repair workshops, and garages.

Key features include a simple and modern design, LED technology, energy efficiency, reliability, dimmability, and, last but not least, affordability.

Additional accessories can be purchased for the LED light: a 120° lampshade and an adjustable bracket, allowing you to customize the lighting angle as needed and easily position or mount the light on a wall.

A hanging hook is included in the package.

ZH driver DIM 0-10V
HONGLI led
PF > 0,96

TECHNICAL PARAMETERS
consumption 150W
luminous flux Φuse - 23600Lm, total - 25500Lm
dimming yes (0-10V)
dimension Ø300x145
chromaticity (light color) 5000K - neutral white
angle of light 90°
voltage AC120 - 277V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 1650
coverage IP65
degree mechanical protection
IK08
material metal - black
type of  diffuser lens, 90°
packing 1/4
LED´s aren´t possible to change



Declaration of conformity

eu_declaration_of_conformity_lu3_4.pdf

Installation instruction

manual_lu4-1.pdf

Photometric data

90°

lu422-1_ies.zip

120°

lu422-1_120d_ies.zip

Product sheet
