LED light UFO 150W / IP65 / 5000K + sensor + standby mode - LU112/SR

Sensor PD
Dimmable:
remote control
Luminous flux (Lm):
22500
Power (W):
150
RP:
consumption (W):

150

luminous flux (Lm):

22500

dimming:

yes

sensor:

yes

dimension (mm):

Ø330 x 128

light color (K):

5000

coverage:

IP65

degree of mechanical protection:

IK08

Producer: NEDES
Warranty: 60 months
Code: LU112/SR
EAN: 8585040904621
Availability: in stock
172.50 excl. VAT
207.00 PCS
Watchdog Add to wishlist Share

SOSEN driver DIM + Senzor + Standby
PHILIPS led
PF > 0,96

production set-up:
2sec (100%) with max. ambient light and standby off eye for hanging-in pack





TECHNICAL PARAMETERS
consumption 150W
luminous flux 22500Lm
dimming yes (remote control RLU112-not included)
sensor yes 5,8GHz (10m/5lx-max/2sec-30min)
standby mode yes (adjustable)
dimension (mm) Ø330 x 128
chromaticity (light color) 5000K - neutral white
angle of light 90°
voltage AC90 - 305V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 2794
coverage IP65
degree mechanical protection
IK08
material metal - black
type of diffuser lens, 90°
packing 1/4
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_lu.pdf

Installation instruction

manual_ufo-150w-sensor-5000k-lu112sr.pdf

Fotometric data

lu112sr_ies.zip
