LED panels 25W-45W

LED panel backlite 40W / 595x595 / SMD / 4000K / WH - PL5024

Light angle:
120
RP:
Luminous flux (Lm):
3000-4999
Installation type:
Ceiling
Dimension (mm):
501-699
Power (W):
31-50
Light source:
LED
Coverage:
IP20
Dimming:
No
Sensor:
No
UGR:
Yes
Shape:
Square
Color rendering index:
Ra≥80
Producer: NEDES
Warranty: 60 months
Code: PL5024
EAN: 8585040910370
Availability: in stock more than 300 pcs
€ 29.84 excl. VAT
€ 36.70 pcs
Watchdog Add to wishlist Share

Description Need advice?

LED panel Backlite PROFI Plus

LIFUD Led driver

PF > 0,90

TECHNICAL PARAMETERS
consumption 40W
luminous flux 4000Lm
glare index - UGR <23
dimension (mm) 595 x 595 x 25
chromaticity (light color) 4000K - neutral white
angle of light 120°
voltage AC220 - 240V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 1305
coverage IP20
material AL - white
type of diffuser opal
possibility dimming no
packing 1/10
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_pl5_6_7.pdf

Installation instruction

manual_pl5024__pl5024u-_backlite_f.pdf

Fotometric data

pl5024_ies.zip
