LED street lightsAsymmetric LED

LED street light 60W / 5000K - LSL522

PD
Light angle:
70 x 140°
RP:
Luminous flux (Lm):
5000-9999
Power (W):
51-80
Coverage:
IP65
Light source:
LED
Dimming:
No
Sensor:
No
Dimension (mm):
≤500
Mounting on a bracket:
Ø60
Color rendering index:
Ra≥80
Producer: NEDES
Warranty: 60 months
Code: LSL522
EAN: 8585040905611
Availability: in stock more than 200 pcs
€ 130.49 excl. VAT
€ 160.50 pcs
Watchdog Add to wishlist Share

Description Need advice?

 ZH driver
HONGLI led
PF > 0,95

TECHNICAL PARAMETERS
consumption 60W
luminous flux Φuse - 7300Lm (120°), total - 8700Lm
dimension (mm) 490 x 190 x 78
outrigger with Ø 60mm
chromaticity(light color) 5000K - neutral white
angle of light 70 x 140°
voltage AC100 - 277V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 1800
coverage IP65
degree mechanical protection
 IK08
material metal - grey
type of diffuser lens, ABS
packing 1/10
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_nedes_-_lsl5_lsl6_lsl7.pdf

Fotometric data

lsl522_ies.zip

Product sheet

product_sheet_lsl522.pdf
