LED panels 25W-45W

LED panel backlite 25W / 295x595 / SMD / 4000K / WH - PL6221

PE
Light color:
neutral white
UGR <19:
no
Depth (mm):
25
Luminous flux (Lm):
3400
Power (W):
32
RP:
Producer: NEDES
Warranty: 60 months
Code: PL6221
EAN: 8585040910417
Availability: in stock more than 300 pcs
€ 23.00 excl. VAT
€ 27.60 pcs
Watchdog Add to wishlist Share

Description Need advice?

LED panel Backlite PROFI Plus

LIFUD Led driver

PF > 0,90

TECHNICAL PARAMETERS
consumption 25W
luminous flux 3000Lm
glare index - UGR <23
dimension (mm) 295 x 595 x 25
chromaticity (light color) 4000K - neutral white
angle of light 120°
voltage AC220 - 240V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 712
coverage IP20
material AL - white
type of diffuser opal
possibility dimming no
packing 1/10
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_pl5_6_7.pdf

Installation instruction

manual_pl-backlite_rectangle.pdf

Fotometric data

pl6221_ies.zip
