LED panels 25W-45W

LED panel backlite 32W / 595x595 / SMD / 4000K / WH / UGR19 - PL5523U

PD
Light color:
neutral white
UGR <19:
yes
Depth (mm):
34
Luminous flux (Lm):
7200
Power (W):
30
RP:
Producer: NEDES
Warranty: 60 months
Code: PL5523U
EAN: 8585040910349
Availability: in stock 48 pcs
€ 41.58 excl. VAT
€ 49.90 pcs
Watchdog Add to wishlist Share

Description Need advice?

LED panel Backlite PROFI Plus

Philips Led driver

PF > 0,90

TECHNICAL PARAMETERS
consumption 32W
luminous flux 4800Lm
glare index - UGR <19
dimension (mm) 595 x 595 x 34
chromaticity (light color) 4000K - neutral white
angle of light 120°
voltage AC220 - 240V
lifespan 50 000h
switching cycle 30 000 x
weight netto (g) 1620
coverage IP20
material AL - white
type of diffuser opal
possibility dimming no
packing 1/5
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_pl5_6_7.pdf

Installation instruction

manual_pl595x595-backlite.pdf

Fotometric data

pl5523u_ies.zip
