LED panels 25W-45W

LED panel backlite 40W / 295x1195 / SMD / 4000K / WH - PL7224

PE
Light angle:
120
RP:
Luminous flux (Lm):
3000-4999
Installation type:
Ceiling
Dimension (mm):
1000≤
Power (W):
31-50
Light source:
LED
Coverage:
IP20
Dimming:
No
Sensor:
No
UGR:
Yes
Shape:
Rectangle
Color rendering index:
Ra≥80
Producer: NEDES
Warranty: 60 months
Code: PL7224
EAN: 8585040910431
Availability: in stock more than 300 pcs
€ 34.72 excl. VAT
€ 42.70 pcs
Watchdog Add to wishlist Share

Description Need advice?

LED panel Backlite PROFI Plus

LIFUD Led driver

PF > 0,90

TECHNICAL PARAMETERS
consumption 40W
luminous flux 4800Lm
glare index - UGR <23
dimension (mm) 295 x 1195 x 25
chromaticity (light color) 4000K - neutral white
angle of light 120°
voltage AC220 - 240V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 1339
coverage IP20
material AL - white
type of diffuser opal
possibility dimming no
packing 1/10
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_pl5_6_7.pdf

Installation instruction

manual_pl-backlite_rectangle.pdf

Fotometric data

pl7224_ies.zip
