LED panels 25W-45W

LED panel backlite 25W / 295x595 / SMD / 4000K / WH / UGR19 - PL6221U

PE
Light angle:
120
RP:
Luminous flux (Lm):
3000-4999
Installation type:
Ceiling
Dimension (mm):
501-699
Power (W):
21-30
Light source:
LED
Coverage:
IP20
Dimming:
No
Sensor:
No
UGR:
Yes
Shape:
Rectangle
Color rendering index:
Ra≥80
Producer: NEDES
Warranty: 60 months
Code: PL6221U
EAN: 8585040910424
Availability: in stock more than 300 pcs
€ 25.28 excl. VAT
€ 31.10 pcs
Watchdog Add to wishlist Share

Description Need advice?

LED panel Backlite PROFI Plus

LIFUD Led driver

PF > 0,90

TECHNICAL PARAMETERS
consumption 25W
luminous flux 3000Lm
glare index - UGR <19
dimension (mm) 295 x 595 x 25
chromaticity (light color) 4000K - neutral white
angle of light 120°
voltage AC220 - 240V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 792
coverage IP20
material AL - white
type of diffuser opal
possibility dimming no
packing 1/10
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_pl5_6_7.pdf

Installation instruction

manual_pl-backlite_rectangle.pdf

Fotometric data

pl6221u_ies.zip
