LED panels 25W-45W

LED panel backlite 40W / 595x595 / SMD / 4000K / WH / UGR19 - PL5224U

PE
RP:
Svetelný tok (Lm):
3000-4999
Typ inštalácie:
Stropné
Rozmer (mm):
501-699
Výkon (W):
31-50
Zdroj svetla:
LED
Krytie:
IP20
Stmievanie:
Nie
Senzor:
Nie
Index oslnenia - UGR:
Áno
Tvar:
Štvorec
Index podania farieb:
Ra≥80
Producer: NEDES
Warranty: 60 months
Code: PL5224U
EAN: 8585040910400
Availability: in stock more than 300 pcs
€ 36.42 excl. VAT
€ 44.80 pcs
Watchdog Add to wishlist Share

Description Need advice?

LED panel Backlite PROFI Plus

LIFUD Led driver

PF > 0,90

TECHNICAL PARAMETERS
consumption 40W
luminous flux 4800Lm
glare index - UGR <19
dimension (mm) 595 x 595 x 25
chromaticity (light color) 4000K - neutral white
angle of light 120°
voltage AC220 - 240V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 1485
coverage IP20
material AL - white
type of diffuser opal
possibility dimming no
packing 1/10
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_pl5_6_7.pdf

Installation instruction

manual_pl595x595-backlite.pdf

Fotometric data

pl5224u_ies.zip

Product sheet

product_sheet_pl5224u.pdf
