LED panels 25W-45W

LED panel UGR 32W / 595x595 / SMD / 4500K / WH / UGR - PL120P/U

Light color:
neutral white
UGR <19:
yes
Depth (mm):
10
Power (W):
30
Luminous flux (Lm):
6000
RP:
Producer: NEDES
Warranty: 60 months
Code: PL120P/U
EAN: 8585040904690
Availability: in stock more than 200 PCS
€ 63.83 excl. VAT
€ 76.60 PCS
Watchdog Add to wishlist Share

Description Need advice?
TECHNICAL PARAMETERS
consumption 32W
luminous flux 4050Lm
glare index - UGR <19
dimension (mm) 595 x 595 x 10
chromaticity (light color) 4500K - neutral white
angle of light 120°
voltage AC220 - 240V
lifespan 40 000h
switching cycle 25 000 x
weight netto (g) 2340
coverage IP20
material AL-white
type of diffuser opal
possibility dimming no
packing 1/10
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_pl.pdf

Installation instruction

instruction_manual_of_panel_light-pl.pdf

Fotometric data

pl120pu_ies.zip
