LED street lightsAsymmetric right LED

LED for street light crossing right 40W / 5000K - LSL621/RP

PD
Light angle:
36 x 106°
RP:
Luminous flux (Lm):
5000-9999
Power (W):
31-50
Coverage:
IP65
Light source:
LED
Dimming:
No
Sensor:
No
Dimension (mm):
≤500
Mounting on a bracket:
Ø50
Color rendering index:
Ra≥80
Producer: NEDES
Warranty: 60 months
Code: LSL621/RP
EAN: 8585040905666
Availability: in stock more than 200 pcs
€ 165.04 excl. VAT
€ 203.00 pcs
Watchdog Add to wishlist Share

Description Need advice?
ZH driver
SEOUL led
PF > 0,95

TECHNICAL PARAMETERS
consumption 40W
luminous flux Φuse - 5800Lm (120°)
dimension (mm) 420 x 210 x 85
outrigger with Ø 50mm
chromaticity(light color) 5000K - neutral white
angle of light 36 x 106°
voltage AC100 - 277V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 3220
coverage IP65
degree mechanical protection
 IK08
material metal - grey
type of diffuser lens, ABS
packing 1/4
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_nedes_-_lsl5_lsl6_lsl7.pdf

Fotometric data

lsl621_rp_ies.zip

Product sheet

product_sheet_lsl621rp.pdf
