LED street lightsAsymmetric LED

LED street light 80W / 5000K - LSL523

PD
Light angle:
70 x 140°
RP:
Luminous flux (Lm):
10000-14999
Power (W):
51-80
Coverage:
IP65
Light source:
LED
Dimming:
No
Sensor:
No
Dimension (mm):
501-699
Mounting on a bracket:
Ø60
Color rendering index:
Ra≥80
Producer: NEDES
Warranty: 60 months
Code: LSL523
EAN: 8585040905628
Availability: in stock 74 pcs
€ 165.45 excl. VAT
€ 203.50 pcs
Watchdog Add to wishlist Share

Description Need advice?

ZH driver
HONGLI led
PF > 0,95

TECHNICAL PARAMETERS
consumption 80W
luminous flux 11600Lm
dimension 550 x 215 x 80
outrigger with Ø 60mm
chromaticity(light color) 5000K - neutral white
angle of light 70 x 140°
voltage AC100 - 277V
lifespan 50 000h
swiching cycle 30 000 x
weight netto (g) 2420
coverage IP65
degree mechanical protection
 IK08
material metal - grey
type of diffuser lens, ABS
packing 1/10
LED´s aren´t possible to change


Declaration of conformity

eu_declaration_of_conformity_nedes_-_lsl5_lsl6_lsl7.pdf

Fotometric data

lsl523_ies.zip

Product sheet

product_sheet_lsl523.pdf
