The asymmetrical LED street light LSL711 by NEDES, with warm white light and a 30W power output, provides efficient illumination for streets, sidewalks, roads, and parks.
This high-performance public lamp ensures strong luminous output and energy efficiency.
Key features include a simple and modern design, LED technology, energy savings, reliability, and affordable pricing.
ZH driver
HONGLI led
PF > 0,95
| TECHNICAL PARAMETERS | |
| consumption | 30W |
| luminous flux | 4500Lm |
| dimension (mm) | 478 x 188 x 69 |
| outrigger with Ø | 60mm |
| chromaticity(light color) | 2700K - warm white |
| angle of light | 70 x 140° |
| voltage | AC100 - 277V |
| lifespan | 50 000h |
| swiching cycle | 30 000 x |
| weight netto (g) | 1475 |
| coverage | IP65 |
| degree mechanical protection |
IK08 |
| material | metal - grey |
| type of diffuser | lens, ABS |
| packing | 1/10 |
| LED´s aren´t possible to change |
